Description
Kollmorgen S712/30-FN2
Technical Specifications
- Product Family: SERVOSTAR S700 Series
- Size Class: S712/30
- Device Designation: S712/30-FN2
- Product Category: Digital servo amplifier
- Rated Line Power (S1): 9 kVA
- Rated Line Voltage: 3×208 V (−10%) to 3×480 V (+10%)
- Rated DC Bus Voltage: 290–675 VDC
- Rated Output Current: 12 Arms at 3×208 V / 3×230 V; 12 Arms at 3×400 V; 12 Arms at 3×480 V
- Peak Output Current: 30 Arms
- Safety: Dual-channel STO (Safe Torque Off)
- Onboard Communication: CANopen and EtherCAT
- Expansion Card: F2 controlled fan option installed in Slot 2
- Certifications: CE, UL, TÜV
Functional Features
- Controlled Fan (F2 Option): Fan switches on/off or runs at 50% speed based on heat sink temperature and brake power, reducing average noise emission
- Fan Switching Thresholds: Fan off below 55°C heat sink / 60°C internal / 20 W brake power; fan at 50% around 58°C / 65°C / 30 W; fan fully on above 65°C / 75°C / 45 W
- Higher Peak Current: 30 Arms peak output current for demanding acceleration requirements
- Multi-Loop Control: High-speed current, velocity, and position control loops
- Autotuning: Automatic PID parameter and feedforward adjustment
- Cogging Suppression: Minimized motor cogging for smooth operation
- Macro Programming: IEC 61131-3 structured text with 128 KB code memory
- Multi-Feedback Support: Up to three simultaneous feedback systems
- Dual-Channel STO: SIL2/PLd compliant safe torque off
- Dynamic Braking: Integrated braking circuit with standard internal braking resistor
- MMC Storage Card Slot: Parameter and firmware backup
