Description
Kollmorgen S72402-NANANA-NA-030
Technical Specifications Series: S700 Servo Drives Rated Output Current: 30 A RMS (±3%) Peak Output Current: 60 A RMS (typical 150-200% of rated) Supply Voltage: 3-phase AC 200-480 VAC, 50/60 Hz Switching Frequency: 10 kHz Power Rating: 11 kW DC Bus Voltage: 290-675 VDC
Performance Parameters The drive delivers high torque output for applications requiring rapid acceleration and deceleration. The advanced thermal management system ensures reliable operation under challenging conditions. The unit supports bandwidth up to 1 kHz for high-speed servo control. Overload protection activates at 130% of full-load current. Short circuit protection is provided through integral solid-state protection circuitry.
Functional Characteristics The S72402-NANANA-NA-030 supports multiple control modes including position, velocity, and torque control. Communication interfaces include EtherCAT, CANopen, and RS232 for seamless integration with control systems. The drive features Safe Torque Off (STO) safety functionality to ensure equipment and personnel safety. Analog command input operates at ±10 V full-scale with 1500 Hz low-pass filter.
Structural Features Dimensions: 170 mm × 415 mm × 350 mm (H×W×D) Mounting: Panel-mounted on conductive, grounded plate using 3×M5 hexagon socket screws Weight: 5-8 kg (typical range for similar servo amplifiers) Cooling: Integrated cooling fan with tool-free removal and reinstallation Protection: IP67-rated enclosure option available
Installation Requirements Mount the drive on a conductive, grounded plate in a control cabinet. Connect 3-phase AC power through RK5/CC/J/T class fuses rated 600 VAC, 200 kA, 30 A time-delay. Wire motor power cables to the output terminals following the user manual specifications. Connect encoder feedback cables to the designated feedback terminals. Install control and communication cables with proper shielding.
Operating Considerations Operating Temperature: -25°C to +70°C (maximum 20 K/hr temperature change) Storage Temperature: -25°C to +55°C Humidity: 5-95% relative humidity (no condensation) Pollution Degree: 2 The drive complies with IEC 61131-2, EN 61800-2, EN 60721-3-1 standards. EMC performance meets noise immunity category 2 for industrial environments. Ensure proper branch circuit protection per NEC and local electrical codes.
