Description
Motorola MVME147-012A
Technical Specifications
- Microprocessor: MC68030.
- Configuration: 012A exclusive hardware combination.
- Bus: Standard VMEbus specification.
Functional Features
- Hardware optimized for specific industrial protocols or control algorithms.
- Supports multiple real-time operating systems (e.g., VxWorks, OS-9).
- Comprehensive board-level diagnostics.
Application Scenarios
Applicable in complex industrial process control, semiconductor manufacturing, aerospace test benches, and legacy system maintenance.
Performance Parameters
- Stable VME bus timing and data transfer rates.
- Excellent EMI and ESD immunity.
Material Composition
Multi-layer industrial-grade PCB with a protective conformal coating.
Structural Characteristics
Standard 6U VME European card size with front-panel debug interfaces and status indicators.
Working Principle
The MC68030 accesses the VME bus via internal cache and external bus interface, executing real-time OS to coordinate peripherals for data acquisition and control.
Installation Requirements
- Requires a dedicated MVME712 series transition module for I/O breakout.
- Ensure chassis provides stable +5V and +12V power.
Usage Precautions
- Distinguish the 012A suffix from other hardware variants.
- Regularly check the on-board battery to prevent SRAM data loss.
