Description
OMRON CS1W-BI083
Technical Specifications:
- Brand: OMRON
- Model: CS1W-BI083
- Product Type: Expansion Backplane
- Compatible System: CS1 Series PLC
- Number of Slots: 8
- Dimensions: 130 mm (H) × 435 mm (W) × 132 mm (D)
- Mounting: DIN Rail or Panel Mount
- RoHS Compliance: Compliant
Functional Features:
- Provides 8 slots for mounting CS1 series I/O and special function units
- Supports C200H series I/O BUS compatibility
- Compact design for space-efficient panel layouts
- Secure mounting for modules to ensure reliable electrical connections
Application Scenarios:
- Expanding the I/O capacity of CS1 series PLC systems
- Industrial automation control panels
- Process control systems requiring multiple special function units
- Factory automation integration
Performance Parameters:
- Slot Count: 8
- System Bus: CS1 I/O Bus
- Max Units: Depends on power supply capacity and unit current consumption
Material Composition:
- High-strength plastic housing
- Copper alloy bus connectors
- Metal mounting brackets
Structural Features: The unit features a robust plastic frame with 8 distinct module slots. It includes mounting holes for DIN rail or direct panel installation.
Working Principle: The backplane distributes power and data signals from the CPU or I/O control unit to the modules inserted into its slots. It acts as a passive bridge, ensuring high-speed data transmission and stable power delivery.
Installation Requirements:
- Mount vertically on a DIN rail or panel.
- Ensure adequate clearance for heat dissipation.
- Connect to the CPU unit or I/O control unit using the appropriate expansion cable.
Usage Notes:
- Ensure the total current consumption of mounted units does not exceed the power supply capacity.
- Do not install or remove modules while the power is ON.
- Verify that the backplane is securely grounded.
