Description
OMRON CS1W-CN223
Technical Specifications:
- Brand: OMRON
- Model: CS1W-CN223
- Product Type: Expansion Cable
- Compatible System: CS1 Series PLC
- Cable Length: 2.0 meters (Typical for CN223 model)
- Connector Type: Dedicated CS1 Expansion Connectors
- Transmission Method: Parallel bus
Functional Features:
- Connects CPU rack to expansion rack
- High-speed data transmission
- Robust shielding against electrical noise
- Easy plug-and-play connection
Application Scenarios:
- System expansion for CS1 PLCs
- Connecting remote I/O racks
- Industrial control panel wiring
Performance Parameters:
- Length: 2.0m
- Data Transmission: High-speed parallel bus
Material Composition:
- Shielded twisted pair cables
- Molded connectors with locking mechanisms
- PVC outer jacket
Structural Features: The cable features specialized connectors at both ends that mate directly with the expansion ports on the CPU unit or I/O control unit and the expansion backplane.
Working Principle: The cable carries the system bus signals (data, address, control) and power lines between the CPU and the expansion backplane, effectively extending the physical footprint of the PLC system.
Installation Requirements:
- Connect one end to the CPU unit or I/O Control Unit.
- Connect the other end to the Expansion Backplane.
- Secure the connectors with the locking screws.
Usage Notes:
- Do not bend the cable sharply (minimum bending radius applies).
- Ensure the cable is not routed near high-voltage power lines to prevent noise interference.
- Verify the connection is secure before powering on the system.
