Description
Foxboro P0912XX
Technical Specifications
- Series: P0912XX
- Type: Termination Assembly / Interface Connector
- Compatible Modules: Various FBM2xx series modules
Functional Features
- Signal Transfer: Provides physical connection from module backplane to field cables.
- Protection Function: Some models have built-in fuses, surge protectors, or isolation transformers.
- Convenient Maintenance: Supports quick plug-and-pull and testing of field cables.
Application Scenarios
As a necessary supporting component for all FBM modules, widely used in wiring terminal blocks inside control room cabinets.
Performance Parameters
- Rated Current/Voltage: Supports standard industrial signal levels depending on the specific model.
- Insulation Resistance: High insulation performance to prevent signal crosstalk.
Material Composition
Flame-retardant plastic base, gold-plated or silver-plated copper alloy contacts to ensure low contact resistance.
Structural Characteristics
- Form: Plug-in terminal blocks or screw wiring terminals.
- Identification: Each terminal has clear channel numbering.
Working Principle
As a pure physical connection and electrical interface device, it leads out FBM module pin signals to external wiring terminals and may contain simple RC filtering or protection circuits.
Installation Requirements
Must be precisely aligned and plugged tightly with the corresponding FBM module. Field cable wiring must be firm to prevent loosening causing signal loss.
Precautions for Use
Never plug or unplug terminal assemblies in a powered state. When replacing, confirm the specific suffix model after P0912XX to ensure a perfect match with the FBM module.
