Description
GE 6KGP43001X9XXXA11HP
Technical Specifications
- Product Series: AF-600 GP
- Power Rating: Configurable based on model designation
- Input Voltage: 380-480VAC, 3-Phase
- Control Modes: V/F, Sensorless Vector, Closed-Loop Vector
- Communication: Built-in Modbus, optional fieldbus adapters
Functional Features
- Energy Savings: Optimized motor control reduces energy consumption.
- Advanced Control: High-performance vector control for precise torque and speed.
- Built-In EMC Filter: Reduces electromagnetic interference.
- Safe Torque Off: Integrated safety function (STO).
Application Scenarios
Pumps, fans, compressors, conveyors, extruders, and general industrial motor control.
Performance Parameters
- Overload Capacity: 110% for 60 seconds, 150% for 3 seconds.
- Speed Range: 1:100 for sensorless vector control.
- Efficiency: >97% at full load.
Material Composition
Industrial-grade power electronics, aluminum heat sink, and robust enclosure.
Structural Characteristics
Compact design with front-panel keypad, LCD display, and terminal blocks for power and control connections.
Working Principle
Converts AC input to DC, then inverts DC to variable frequency/voltage AC using IGBTs to control motor speed and torque.
Installation Requirements
Mount in a well-ventilated location. Provide adequate clearance for cooling. Wire according to NEC and local codes.
Usage Precautions
Never connect power to output terminals. Allow capacitors to fully discharge before servicing. Set motor parameters correctly to prevent damage.
