Description
GE 6KGP43030X9XBXA1
Technical Specifications
- Drive Series: GE AF-600 GP
- Motor Power Rating: 30 HP (22 kW)
- Input Voltage: 380-480V AC, 3-Phase
- Output Current: 45A (Typical for this rating)
Functional Features
- Sensorless vector control for high starting torque and precise speed regulation.
- Built-in EMC filter and DC choke for reduced harmonic distortion.
- Integrated safe torque off (STO) functionality for enhanced personnel safety.
Application Scenarios
Ideal for centrifugal pumps, fans, conveyors, compressors, and extruders in water treatment, HVAC, and manufacturing facilities.
Performance Parameters
- Overload capacity of 110% for 60 seconds.
- High switching frequency for quiet motor operation.
Material Composition
Robust metal enclosure with advanced IGBT power modules and copper buswork.
Structural Characteristics
Compact, wall-mountable form factor with an integrated LED operator display and keypad for local parameter configuration.
Working Principle
Converts incoming AC power to DC, then uses pulse-width modulation (PWM) via IGBTs to synthesize a variable frequency and voltage AC output to precisely control motor speed and torque.
Installation Requirements
- Mount vertically with adequate clearance for top and bottom ventilation.
- Connect motor and power cables using shielded VFD-rated cable.
- Ensure proper grounding to minimize electromagnetic interference.
Usage Precautions
- Wait at least 5 minutes after power-down for internal DC bus capacitors to discharge before servicing.
- Never disconnect the motor while the drive is running.
- Verify motor nameplate data matches drive programming parameters.
