Description
GE 745-W2-P5-G5-HI-A-L
Technical Specifications
- Product Series: GE Multilin 745 Motor Management System
- Configuration Code: W2-P5-G5-HI-A-L (Specific option package)
- Protection Functions: Overload, phase unbalance, ground fault, under/over voltage, and thermal capacity modeling.
Functional Features
- Advanced Thermal Modeling: Calculates motor thermal capacity based on actual operating conditions and ambient temperature.
- Metering & Monitoring: Provides real-time voltage, current, power, and energy data.
- Communication Ready: Supports Modbus RTU/TCP and Profibus DP for SCADA integration.
Application Scenarios
Pump stations, compressor drives, conveyor systems, and heavy industrial motor applications.
Performance Parameters
- Measurement Accuracy: High-precision current and voltage sensing.
- Trip Response: Fast and deterministic fault clearing.
Material Composition
Robust industrial enclosure with precision current transformers and microprocessor-based logic board.
Structural Characteristics
Compact panel-mount or DIN-rail form factor with front-panel LCD display and navigation keys.
Working Principle
Continuously samples motor electrical parameters via CTs and VTs, compares them against configured protection curves, and opens the trip relay if an abnormal condition is detected.
Installation Requirements
- Route CT and VT wiring according to the Multilin 745 manual.
- Configure the relay parameters using the EnerVista setup software.
- Ensure proper grounding of the relay chassis.
Usage Precautions
- Never bypass protection functions during operation.
- Verify CT ratios and motor nameplate data match relay settings.
- Perform primary injection testing to validate protection curves.
