Description
GE ADS22200HD
Technical Specifications
- Drive Type: AC Variable Frequency Drive.
- Power Rating: High-duty industrial rating.
- Input/Output: 3-phase AC, various voltage classes.
Functional Features
- Vector Control: Sensorless and closed-loop flux vector control.
- Programmable Logic: Built-in PLC functionality for standalone operation.
- Communication: Supports Modbus, Profibus, DeviceNet, and Ethernet/IP.
Application Scenarios
Applied in pumps, fans, compressors, extruders, and centrifuges across water, mining, and manufacturing industries.
Performance Parameters
- Overload Capacity: 150% for 60 seconds, 180% for 3 seconds.
- Speed Range: 1000:1 in closed-loop vector mode.
Material Composition
Robust metal enclosure, aluminum heat sink, IGBT power modules, and conformal-coated control boards.
Structural Characteristics
Wall-mount or floor-standing enclosure with integrated operator interface, cooling fans, and standardized power/control terminals.
Operating Principle
Converts AC input to DC, then synthesizes variable-frequency AC output using PWM switching to precisely control motor speed and torque based on reference commands.
Installation Requirements
Provide adequate clearance for cooling airflow. Connect input/output reactors if required. Ground drive and motor per NEC/local codes.
Usage Precautions
Never disconnect motor while drive is running. Observe deceleration time to prevent overvoltage faults. Perform auto-tuning after motor replacement.
