GE DS200GGDAG1A
GE DS200GGDAG1A - Image 2

GE DS200GGDAG1A

Product Introduction: The DS200GGDAG1A is a key excitation control board in the GE Speedtronic Mark V turbine control system, responsible for converting digital control commands from the main controller into analog drive signals for SCR (thyristor) power units in generator AVR (Automatic Voltage Regulation) systems.

Request Quote
Category:

Description

GE DS200GGDAG1A

  • Technical Specifications:
    • System: Speedtronic Mark V
    • Analog Outputs: 2 independent ±10 V DC channels
    • Isolation: Optical isolation + transformer isolation
    • Mounting: Mark V I/O rack (VME-based)
    • Operating Temp: 0°C to +60°C
  • Functional Features: High-precision D/A conversion; feedback acquisition from SCR bridge; output limiting and protection logic; onboard LED indicators (Power, OK, Fault); VME backplane communication with TCEA/TCCA controller cards.
  • Application Scenarios: Generator excitation control in gas/steam turbine power plants, synchronous generator AVR loops, industrial cogeneration units, hydro-turbine voltage regulation systems.
  • Performance Parameters: Output stability maintained under 60°C ambient; common-mode noise rejection via dual isolation; supports dual-channel redundant excitation or dual-range control; compatible with Mark V triple modular redundant architecture.
  • Material Composition: Multilayer controlled-impedance PCB; precision D/A converters and op-amps; optically coupled isolators; gold-plated VME connector fingers; conformal coating for humidity resistance.
  • Structural Features: 6U VME card with front faceplate containing status LEDs; edge connector for backplane power/data; surface-mounted components; silkscreened test points for calibration verification.
  • Working Principle: Receives digital excitation demand values from the Mark V main processor via VMEbus, converts them to ±10 V analog signals via precision D/A converters, isolates these signals galvanically, and drives the SCR firing circuitry to regulate generator field current, thereby stabilizing terminal voltage.
  • Installation Requirements: Insert into assigned Mark V I/O slot ensuring full engagement with J1/J2 backplane; verify that associated terminal boards (e.g., for feedback) are cabled correctly; ensure 28 V DC backplane power is within tolerance before rack energization.
  • Usage Precautions: Static discharge can destroy D/A converters—use grounded wrist strap; if replacing a failed board, compare jumper/dip-switch settings with the removed unit; monitor OK/Fault LEDs during commissioning—Fault lit indicates backplane communication loss or output overload.
