Description
GE DS200LDCCH1ANA
Technical Specifications
- Part Number: DS200LDCCH1ANA
- Board Type: Drive Logic / Control Board
- System Compatibility: GE DS200 Series Drives
- Processing: Microprocessor-based control logic
Functional Features
- Control Algorithm Execution: Runs vector control, V/Hz, or PID loops for motor regulation.
- System Management: Coordinates operation between power, feedback, and communication boards.
- Fault Protection: Monitors for overcurrent, overvoltage, and ground faults.
Application Scenarios
Variable frequency drives, pump and fan control, and industrial process automation.
Performance Parameters
- Scan Time: Fast deterministic processing for real-time motor control.
- Memory: Sufficient RAM/Flash for storing parameters and fault logs.
Material Composition
High-speed microprocessors, memory ICs, and multi-layer digital PCB.
Structural Characteristics
Standard DS200 form factor with high-density backplane connectors and configuration jumpers.
Working Principle
The board continuously samples motor current and speed, compares them to the setpoint, and adjusts the PWM output to the power stage to maintain precise control.
Installation Requirements
- Insert into the designated logic slot in the DS200 chassis.
- Verify all configuration jumpers match the motor and application requirements.
- Ensure the backplane connector is fully seated.
Usage Precautions
- Never remove the board while drive control power is active.
- Backup drive parameters before replacing the logic board.
- Observe strict ESD handling procedures.
