GE DS200SLCCG3A
Technical Specifications
- Part Number: DS200SLCCG3A
- Type: Simplex Logic Controller
- I/O: Integrated digital and relay outputs
- Programming: DIP switch or software configurable
Functional Features
- Logic Execution: Implements AND/OR/NOT logic functions.
- Relay Outputs: Direct control of external loads.
- Status Indication: LED diagnostics for each channel.
Application Scenarios
Auxiliary control panels, interlock systems, and simple automation tasks.
Performance Parameters
- Logic Speed: Deterministic relay and solid-state switching.
- Contact Rating: Rated for industrial load currents.
Material Composition
Electromechanical relays, solid-state switches, and logic ICs.
Structural Characteristics
Compact card format with terminal blocks and status LEDs.
Working Principle
Input signals are evaluated against configured logic rules, and outputs are energized based on the resulting logic state.
Installation Requirements
- Mount in appropriate DIN rail or panel enclosure.
- Wire inputs and outputs per schematic.
- Configure logic settings before operation.
Usage Precautions
- Do not exceed relay contact ratings.
- Provide flyback diodes for inductive loads.
- Verify logic configuration matches application requirements.
