Description
GE DS200TBQBG1A
Technical Specifications
- Manufacturer: General Electric (GE)
- Product Series: DS200 Drive Control
- Board Type: Motor Drive Control PCB
- Revision: G1A
Functional Features
- Motor Regulation: Executes advanced control algorithms for precise speed and torque regulation.
- System Diagnostics: Continuously monitors drive health and reports faults to the operator.
- Parameter Storage: Retains drive configuration and motor nameplate data.
Application Scenarios
DC and AC motor drives, industrial inverters, hoists, and variable frequency drive (VFD) applications.
Performance Parameters
- Control Accuracy: High-precision feedback processing for smooth motor operation.
- Response Time: Fast dynamic response to load changes and command updates.
Material Composition
Multi-layer printed circuit board with gold-plated edge connectors and industrial-grade surface-mount components.
Structural Characteristics
Standard drive board form factor with plug-in connectors, adjustment potentiometers, and LED status indicators.
Working Principle
Receives speed/torque reference signals and motor feedback, processes the error through internal control loops, and outputs precise gate drive signals to the power stage.
Installation Requirements
Carefully align the board with the backplane or mating connectors. Secure with designated mounting hardware to prevent vibration damage.
Usage Precautions
Always observe strict ESD protocols. Never insert or remove the board while the drive is powered on. Backup drive parameters before replacing the board.
