Description
GE DS200TBQDG1AFF
Technical Specifications
- Board Type: RST Analog I/O Board
- Series Compatibility: GE Speedtronic Mark V
- Connectors: Features multiple 34-pin and 40-pin connectors, and hardware jumpers.
Functional Features
- Scales and conditions analog signals including LVDT inputs, servo valve outputs, thermocouples, 4-20 mA signals, and vibration inputs.
- Transmits conditioned signals to the STCA board via the 3PL data bus connector.
- Sends and receives generator and line signals through the JE connector.
Application Scenarios
Exclusively deployed in power generation plants utilizing GE Mark V turbine control systems for precise monitoring and regulation of turbine operational parameters.
Performance Parameters
- High-precision analog signal scaling with low noise interference.
- Deterministic processing speed for real-time turbine safety and control.
Material Composition
Industrial-grade multi-layer printed circuit board (PCB) featuring advanced microprocessors and conformal coating.
Structural Characteristics
Standard Mark V rack-mountable form factor designed for secure installation in the drive cabinet.
Working Principle
Acquires raw analog signals from field sensors via terminal boards, applies necessary scaling and conditioning, and routes the digital data across the core bus for the central processor.
Installation Requirements
- System must be completely powered down before replacement.
- Carefully document and label all ribbon cable connections before removal.
- Match all hardware jumper settings exactly to the original board.
Usage Precautions
- Strictly observe Electrostatic Discharge (ESD) protocols.
- Ensure no loose screws or washers fall into the drive interior during installation.
