GE DS200TCQBG1AFB

GE DS200TCQBG1AFB

Product Introduction
The DS200TCQBG1AFB is a thyristor firing control board used in GE drive systems. It provides precise gate pulse generation for SCR-based power converters, ensuring smooth motor control and efficient power conversion.

Request Quote
Category:

Description

GE DS200TCQBG1AFB

Technical Specifications

  • Output: 6 thyristor gate drive channels
  • Firing Angle: 0-180 degrees programmable
  • Synchronization: 3-phase synchronization inputs
  • Protection: Overcurrent and overvoltage protection

Functional Features

  • Precise Firing: Microsecond-level timing accuracy.
  • Pulse Transformer Isolation: Galvanic isolation between control and power circuits.
  • Fault Monitoring: Real-time thyristor health monitoring.

Application Scenarios
DC motor drives, industrial rectifiers, and HVDC power conversion systems.

Performance Parameters

  • Firing Resolution: 0.1 degree.
  • Response Time: <10 µs.

Material Composition
High-voltage rated components with pulse transformers and optocouplers.

Structural Characteristics
Compact board with high-voltage terminal blocks and status LEDs.

Working Principle
Synchronizes with the AC line voltage, calculates the required firing angle based on control signals, and generates isolated gate pulses to trigger the thyristors.

Installation Requirements
Ensure proper phasing of synchronization inputs. Verify gate pulse wiring polarity.

Usage Precautions
Never operate with open gate circuits. Inspect pulse transformers periodically for signs of arcing.
