Description
GE DS3800HLCA1B1B
Technical Specifications
- Manufacturer: General Electric (GE)
- Product Series: Mark IV Turbine Control
- Board Type: Analog/Digital I/O Board
- Channels: Multiple isolated I/O channels
Functional Features
- Field Interface: Connects to temperature, pressure, and speed sensors.
- Signal Isolation: Galvanic isolation protects control electronics from field transients.
- Diagnostics: Built-in channel health monitoring and fault indication.
Application Scenarios
Gas and steam turbine control systems, compressor stations, and power generation facilities.
Performance Parameters
- Accuracy: High-precision analog-to-digital conversion.
- Isolation Voltage: High-voltage isolation for field safety.
Material Composition
Precision analog components with protective conformal coating and rugged PCB construction.
Structural Characteristics
Mark IV standard board format with rear backplane connector and front-panel terminal blocks or connectors.
Working Principle
Conditions and converts field signals to digital values for the Mark IV processor, and converts digital control outputs to analog/digital signals for field actuators.
Installation Requirements
Install in designated Mark IV rack slot. Wire field connections using shielded cable with proper grounding.
Usage Precautions
Verify field wiring before energizing. Do not apply voltage to output channels. Follow ESD precautions during handling.
