Description
GE DS3800NOWA1K1K
Technical Specifications
- Product Line: GE Speedtronic Mark IV.
- Part Number: DS3800NOWA1K1K.
- Board Type: Turbine Control / Signal Conditioning Board.
- Suffix: 1K1K (Specific revision and feature set).
Functional Features
- Precision Signal Conditioning: Processes turbine sensor signals with high accuracy.
- Redundancy Compatibility: Designed for redundant safety systems.
- Actuator Interface: Controls and monitors turbine control valves.
- Diagnostics: Comprehensive onboard fault detection.
Application Scenarios
Critical component in gas and steam turbine control systems.
Performance Parameters
- Signal Accuracy: High-resolution analog processing.
- Safety Integrity: SIL-rated safety functions.
- Environmental Rating: Withstands turbine enclosure conditions.
Material Composition
Multi-layer PCB with conformal coating and gold-plated connectors.
Structural Characteristics
Standard Mark IV board with test points, LEDs, and edge connector.
Working Principle
Conditions sensor signals and interfaces with Mark IV core processor for safe turbine operation.
Installation Requirements
Install in designated rack slot. Ensure proper alignment.
Usage Precautions
Never hot-swap. Verify exact part number and suffix. Follow safety protocols.
