Description
GE EZSFPA36AT0250
Technical Specifications:
- Brand: General Electric (GE)
- Model: EZSFPA36AT0250
- Product Type: Molded Case Circuit Breaker
- Rated Current: 250 Amperes
- Voltage Rating: 600V AC
Functional Features:
- Advanced Protection: Integrates precise thermal-magnetic or electronic trip units to accurately detect and interrupt fault conditions.
- High Interrupting Capacity: Capable of safely breaking high fault currents without sustaining damage.
- Visual Indicators: Features a clear ON/OFF/TRIP handle position indicator for rapid status assessment.
Application Scenarios:
Industrial power distribution panels, motor control centers, heavy machinery power feeds, and commercial building main feeders.
Performance Parameters:
- Breaking Capacity: High short-circuit current rating (SCCR) ensuring system safety during severe faults.
- Mechanical Life: Rated for tens of thousands of open/close operations.
Material Composition:
Housed in a high-strength, flame-retardant thermoset plastic enclosure with silver-alloy contacts and copper busbars.
Structural Characteristics:
Compact, modular design with bolt-on or plug-in mounting options, featuring a robust toggle handle and auxiliary contact mounting provisions.
Working Principle:
Continuously monitors the current flowing through its contacts. Upon detecting an overload or short circuit, the internal trip mechanism releases the latch, forcing the contacts apart to extinguish the resulting electrical arc and isolate the faulted circuit.
Installation Requirements:
Must be mounted in a properly rated electrical enclosure. Power connections must be torqued to the manufacturer’s exact specifications to prevent overheating.
Precautions for Use:
Always perform lockout/tagout (LOTO) procedures before installation or maintenance. Never exceed the rated voltage or current capacity.
