Description
GE G6M-9UH-00K UR9GH
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE Fanuc (General Electric) |
| Model | G6M-9UH-00K UR9GH |
| Product Type | CPU Module / Control Module |
| Series | PACSystems RX3i / Universal Relay (UR) |
| Processor Speed | 800 MHz |
| Memory | 256 MB RAM |
| Flash Storage | 512 MB |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Humidity | Up to 95% non-condensing |
| Power Supply | 125–250 VDC or 100–240 VAC |
| Power Consumption | 35 W maximum |
| Frequency | 50/60 Hz |
| Digital Inputs | Configurable up to 24 |
| Input Voltage | 24–250 VDC |
| Relay Outputs | Up to 8 |
| Contact Rating | 30 A at 250 VAC |
| Communication Ports | 2 Ethernet, 1 RS485 |
| Protocols | IEC 61850, Modbus, DNP 3.0 |
| Ethernet Baud Rate | Up to 100 Mbps |
| Fiber Optic Support | 100Base-FX |
| Data Logging Rate | 1 ms resolution |
| Event Recording | 1024 events |
| Processing Latency | 2 ms typical |
| Physical Dimensions | 19-inch rack, 4U height |
| Weight | 8 kg |
| Display | Compatible with 128 × 64 pixel LCD |
Key Features
-
High-Performance Processing: 800 MHz processor with 256 MB RAM ensures rapid execution of complex control algorithms.
-
Flexible Communication: Dual Ethernet ports and RS485 support multiple industrial protocols including IEC 61850, Modbus, and DNP 3.0.
-
Robust Data Logging: 1 ms resolution data logging with 1024 event recording capacity for detailed operational analysis.
-
Wide Input Voltage Range: Accepts both AC and DC power inputs (125–250 VDC / 100–240 VAC) for versatile deployment.
-
High-Density I/O: Supports up to 24 digital inputs and 8 relay outputs with high contact ratings.
-
Fiber Optic Capability: 100Base-FX fiber optic support for noise-immune long-distance communication.
-
Industrial Hardening: Operates reliably from -40°C to +60°C with high humidity tolerance.
Applications
-
Industrial automation and process control
-
Power generation and distribution control
-
Substation automation and protection
-
Turbine control system upgrades
-
Water and wastewater treatment plants
-
Oil and gas pipeline control
Installation Requirements
-
Mount in standard 19-inch equipment rack (4U height required).
-
Ensure adequate ventilation for 35 W thermal dissipation.
-
Provide UPS or battery backup for critical applications.
-
Use shielded Ethernet cables for communication ports.
-
Follow ESD precautions during installation and maintenance.
