GE IC200PWB101D Technical Specifications:
- Product Line: GE Fanuc VersaMax Series.
- Function: Power boosting and module base.
- Form Factor: VersaMax Nano/Micro base footprint.
- Power Output: Regulated 5V DC and 3.3V DC backplane power.
Functional Features:
- Integrated Power: Combines the mechanical base and power supply into a single compact unit.
- Modular Expansion: Provides the physical and electrical foundation for stacking additional VersaMax I/O modules.
- Backplane Connectivity: Ensures reliable data and power communication across the entire module string.
Application Scenarios:
- Distributed control panels in packaging machinery.
- Material handling systems requiring localized control.
- Retrofitting older systems to increase processing and I/O capacity.
Performance Parameters:
- Backplane Current Capacity: Sufficient to support a full complement of VersaMax Nano or Micro I/O modules.
- Voltage Regulation: Tight tolerance on 5V and 3.3V outputs to protect sensitive microprocessors.
- Transient Protection: Built-in protection against voltage spikes and surges.
Material Composition & Structural Characteristics:
- Base Material: High-impact, glass-filled thermoplastic.
- Contacts: Gold-plated backplane pins for low-resistance connections.
- Mechanical Latches: Integrated DIN rail latches with positive locking mechanisms.
Working Principle: The PWB101D acts as both a mechanical anchor and a power distribution hub. It receives primary power, converts it to backplane voltages, and distributes it horizontally through the backplane pins to adjacent modules.
Installation Requirements:
- DIN Rail: Must be mounted on a standard 35mm DIN rail.
- Alignment: Ensure the backplane pins are perfectly aligned before sliding adjacent modules into place.
- Grounding: Connect the chassis ground terminal to a clean earth ground.
Usage Precautions:
- Module Compatibility: Verify that all attached modules are compatible with the VersaMax Nano/Micro platform.
- Torque: Do not over-tighten terminal screws to avoid stripping the threads.
- ESD: Observe standard electrostatic discharge precautions when handling the base.
