Description
GE IC610MDL179
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Line | Series One PLC |
| Module Type | Digital Output Module |
| Number of Points | 8 Points |
| Output Voltage | 110-220 VAC |
| Output Current | Up to 2A per point |
| Logic Type | Positive/Negative configurable |
| Slot Requirement | Single slot rack mountable |
| Status Indicators | LED per output point |
Functional Features:
- Provides up to 16 output channels across compatible configurations
- Each channel operates independently with individual control capability
- Supports both DC and AC load driving capabilities
- Designed for easy integration with Series One PLC systems
- Compatible with basic memory configuration up to 95KB user memory
Application Scenarios:
- Industrial automation machinery control
- Valve actuation systems
- Relay switching applications
- Lighting and indicator control circuits
- Motor starter control interfaces
- Process equipment monitoring systems
Performance Parameters:
| Parameter | Value |
|---|---|
| Operating Voltage | 110-220 VAC |
| Load Type | Resistive/Inductive loads supported |
| Response Time | Fast switching capability |
| Isolation | Between common and load circuit |
| Operating Temperature | -25°C to +70°C (typical range) |
| Environmental Rating | Suitable for industrial environments |
Construction Characteristics:
- Compact single-slot module design
- Metal housing with heat dissipation features
- Screw-terminal connection interface
- LED status indication for each output channel
- Mounts on standard Series One rack system
Installation Requirements:
- Must be installed in compatible Series One PLC rack
- Provide proper AC power supply matching voltage requirements
- Secure mounting screws should be tightened appropriately
- Connect load wires to terminal blocks with recommended torque
- Maintain safe separation from high-voltage power lines
Usage Precautions:
- Verify AC voltage before powering the module
- Deactivate system power before changing modules when hot-swapping
- Use appropriate fuses for overload protection
- Do not exceed rated current per output point
- Note: This module is discontinued; consider replacement options
