GE IC660EBA106M
Technical Specifications
- Product Line: GE Fanuc IC660 Genius I/O.
- Part Number: IC660EBA106M.
- Type: Genius Bus Electronic Assembly.
- Bus Type: Genius Serial Bus.
Functional Features
- Intelligent Node: Performs local diagnostics, scanning, and data buffering.
- Hot Swap Capability: Supports replacement of I/O modules without powering down the bus.
- Redundant Communication: Supports dual Genius Bus for fault tolerance.
- Extensive Diagnostics: Reports wire breaks, short circuits, and module faults.
Application Scenarios
Deployed in distributed control systems, remote I/O stations, and large-scale manufacturing automation.
Performance Parameters
- Bus Speed: 156.25 Kbps Genius Bus communication.
- Scan Time: Fast I/O scanning and data update.
- Node Capacity: Supports multiple I/O modules per node.
Material Composition
Industrial-grade PCB with conformal coating, ruggedized connectors, and high-reliability components.
Structural Characteristics
Compact electronic assembly that mounts directly to I/O baseplates. Features Genius Bus connectors, status LEDs, and configuration switches.
Working Principle
Communicates with the PLC or DCS over the Genius Bus, scans local I/O modules, and exchanges data packets. It performs local diagnostics and reports faults to the host controller.
Installation Requirements
Mount to compatible IC660 baseplate. Connect Genius Bus cables with proper termination. Configure node address via DIP switches or software.
Usage Precautions
Observe proper bus termination. Do not disconnect bus cables while powered. Verify node address before installation.
