Description
GE IC695ALG616-EA
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 8 points (galvanically isolated) |
| Input Signal Types | Voltage: ±10V, ±5V, 0-10V, 0-5V Current: 0-20mA, 4-20mA |
| Resolution | 16-bit |
| Accuracy | ±0.05% of full scale |
| Throughput | Up to 8 channels per 10ms |
| Isolation Voltage | 500V AC continuous between channels and backplane |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5% to 95% (non-condensing) |
| Backboard Current Draw | 380mA at 5V DC |
| Terminal Type | Removable terminal block |
| Indicators | 8 individual LEDs for channel status |
Functional Characteristics
- Enhanced Accuracy: Superior precision for critical measurements (e.g., gas flow analysis, chemical dosing).
- Multi-Range Flexibility: Software-configurable ranges reduce hardware complexity and cost.
- Robust Isolation: High-grade galvanic isolation ensures reliable performance in electrically noisy environments.
- Advanced Diagnostics: Includes open-wire detection, range alarms, and self-test features for predictive maintenance.
Application Scenarios
- Pharmaceutical Manufacturing: Precise monitoring of drug formulation processes.
- Metrology: Calibration equipment and high-precision weighing systems.
- Environmental Control: Monitoring gas concentrations and pressure in cleanrooms.
- Energy Research: Accurate measurement of power quality and fuel cell performance.
Installation & Usage Notes
- Requires periodic calibration to maintain accuracy (refer to GE maintenance schedules).
- Use low-thermal EMF connectors for temperature-sensitive applications.
- The EA suffix indicates enhanced accuracy; verify compatibility with specific software versions.
- Ensure proper grounding of the terminal block to minimize offset drift.
