Description
GE IC697CMM742-LLNSFS
Technical Specifications
- Part Number: IC697CMM742-LLNSFS
- Product Type: TCP/IP Ethernet (Type 2) Interface Module
- System Compatibility: GE Fanuc Series 90-70 PLC
- Network Protocols: IEEE 802.2 Logical Link Control Class I LAN and IEEE 802.3 CSMA/CD 10Mbps LAN
- Configuration Software: Requires IC641 programming software version 6.02 or higher
Functional Features
- Multi-Port Connectivity: Features three distinct network ports (10Base-T RJ-45, 10Base2 BNC, and AUI) for flexible network integration.
- Serial Management: Includes an RJ-11 RS-232 local station manager port and a 15-pin D-sub RS-485 software loading port for firmware updates.
- Direct Network Operation: Supports direct operation on 10Base-T and 10Base2 media via computer network ports.
- LED Diagnostics: Equipped with four front-panel LEDs indicating module health, LAN online status, serial activity, and overall system status.
Application Scenarios
Extensively deployed in manufacturing automation, power generation, water treatment facilities, and chemical processing plants requiring reliable Ethernet data exchange and remote monitoring.
Performance Parameters
- Backplane Current Draw: 2.0 Amperes at +5V DC and 0.5 Amperes at +12V DC.
- Operating Temperature: 0°C to 50°C (standard industrial range).
- Storage Temperature: -20°C to 60°C.
- Protection Rating: IP65 front panel rating for dust and water resistance.
Material Composition
Constructed with industrial-grade printed circuit boards, ruggedized metallic connectors, and a high-impact plastic housing designed to withstand harsh industrial environments.
Structural Characteristics
Standard Series 90-70 single-slot module footprint featuring multiple front-panel network interfaces and diagnostic indicator lights.
Working Principle
The module interfaces directly with the 90-70 backplane, utilizing an independent communication processor to handle TCP/IP stack operations. This offloads the main CPU, ensuring deterministic data transfer and stable real-time network communication.
Installation Requirements
- Insert into any available I/O slot in the Series 90-70 rack.
- Requires a PLC power supply capable of providing +5V DC and +12V DC.
- Ensure proper network cable termination and shielding for Ethernet connections.
Usage Precautions
- Never connect or disconnect network cables while the module is powered.
- Verify IP address configurations and subnet masks match the network topology.
- Maintain adequate ventilation around the module to prevent thermal overload.
