  • Product Introduction: This is a PCMCIA (Personal Computer Memory Card International Association) communication module for the GE Fanuc 90-70 PLC. It provides a single PCMCIA Type II slot that accepts various communication cards (modems, Ethernet cards, serial cards, wireless cards) to extend the PLC’s communication capabilities. The “P” suffix indicates a specific variant (often related to the number of slots or supported protocols). This module transforms the 90-70 PLC into a versatile communication gateway supporting serial, Ethernet, cellular, and wireless protocols.
Request Quote
Category: SKU: GE IC697PCM711P

Description

GE IC697PCM711P

  • Technical Specifications:
    • Slots: 1 x PCMCIA Type II slot
    • Supported Cards: Serial (RS-232/RS-485), Ethernet (10/100Base-TX), GSM/GPRS cellular modems, 802.11b/g wireless cards, SD memory cards
    • Backplane Interface: IC697 Genius Bus
    • Power Supply: 5VDC from backplane (200mA typical) + 3.3V for card
    • Operating Temperature: 0°C to 60°C
    • Dimensions: Standard IC697 module form factor
  • Functional Features:
    • Single Type II slot for plug-in communication cards
    • Supports hot-swap of PCMCIA cards (with proper configuration)
    • LED indicators: Power, Card Detect, Communication Activity
    • Compatible with 90-70 CPU programming software
    • Supports multiple protocols simultaneously (depending on card)
    • Some variants support 2 slots (check exact model)
  • Application Scenarios:
    • Remote site communication via GSM/GPRS cellular modem
    • Wireless Ethernet bridge for mobile or temporary installations
    • Serial communication with legacy devices (barcode scanners, scales)
    • SD card data logging for recipe storage
    • Remote programming via wireless Ethernet
    • Backup communication path for critical applications
  • Performance Parameters:
    • Serial Speed: Up to 115.2 kbps (RS-232), up to 10 Mbps (RS-485 via card)
    • Ethernet Speed: 10/100 Mbps (via Ethernet card)
    • Cellular: GSM/GPRS Class 10, up to 85.6 kbps
    • Wireless: 802.11b/g, up to 54 Mbps
    • Isolation: 500V RMS optical (backplane to card)
    • ESD: ±8kV contact
  • Material Composition:
    • Housing: UL94 V-0 ABS
    • PCB: 4-layer FR-4, conformal coated
    • Connector: PCMCIA Type II socket with eject mechanism
    • Isolation: Opto-isolators for backplane interface
    • LEDs: Green, Yellow, Red
  • Structural Features:
    • Standard IC697 module size
    • card slot on front panel with eject button
    • 3 LED indicators
    • DIN-rail mount
  • Working Principle:
    • The module provides a interface connected to the CPU via the Genius Bus. When a PCMCIA card is inserted, the CPU detects it and loads the appropriate driver. Data from the card (serial, Ethernet, cellular) is encapsulated into Genius Bus frames and sent to the CPU. The CPU processes the data as if it came from a built-in communication port.
  • Installation Requirements:
    • Mount in IC697 chassis
    • Insert compatible card (verify compatibility list)
    • Configure communication parameters in PLC software
    • For cellular: install external antenna via SMA connector (if available)
  • Usage Precautions:
    • Use only GE-approved cards — third-party cards may not be supported
    • Do not insert/remove cards with power on unless hot-swap is enabled
    • For cellular: ensure antenna is properly connected for signal strength
    • Keep PCMCIA slot clean — dust can cause poor contact
    • Verify card firmware is compatible with PLC firmware version
