Product Introduction
The IC754VBF15CTD-KH is a high-performance 15-inch TFT touch-screen operator interface belonging to the GE QuickPanel+ family. Designed for maximum flexibility, this all-in-one microcomputer integrates a high-resolution display with extensive communication options, serving as a critical human-machine interface (HMI) for connecting operators to industrial equipment and PLCs.

Request Quote
Category:

Description

GE IC754VBF15CTD-KH

Technical Specifications

  • Display Size: 15-inch TFT color touch screen.
  • Configuration: Fully loaded model with integrated communication ports.
  • Power Supply: 24VDC nominal input.
  • Processor: Advanced ARM core microprocessor.
  • Dimensions: 192 mm × 137 mm × 36 mm.
  • Weight: 0.800 kg.

Functional Features

  • Versatile Connectivity: Supports multiple communication ports to interface with most industrial equipment and PLCs.
  • Interactive Display: High-resolution touch screen with adjustable brightness and backlight configuration.
  • System Indicators: Tri-color LED for visual status (Amber/Green/Red) and an on-board buzzer for audio indications.
  • Expansion: SD card slot for data logging and firmware updates.

Application Scenarios
Extensively utilized in industrial automation, process control, machine building, and manufacturing environments requiring reliable local monitoring and control.

Performance Parameters

  • Enclosure Rating: IP65 and JEM1030 when properly installed.
  • Vibration Resistance: 5 to 9Hz single-amplitude 3.5mm; 9Hz to 150Hz constant-accelerated velocity 9.8m/s².
  • Ambient Operating Temperature: 0°C to +50°C.
  • Ambient Humidity: 85% RH (non-condensing).

Material Composition
Constructed with industrial-grade polycarbonate bezel, ruggedized TFT glass, and high-reliability internal PCBs designed to withstand harsh factory environments.

Structural Characteristics
Features a robust front panel with a pre-installed gasket for sealing. Supports panel cutout dimensions of 183.5 mm × 128.5 mm and includes a standard 75 mm x 75 mm VESA mount on the rear.

Working Principle
The ARM-based microprocessor executes the runtime visualization software, processing touch inputs and updating the display via the TFT controller. It communicates bidirectionally with field devices via serial or Ethernet ports to read tags and write control commands.

Installation Requirements
Must be installed in a well-ventilated location protected from dust, corrosive gases, and direct sunlight. Requires a 24VDC power supply connected via the quick-connect terminal block.

Usage Precautions
Always execute a proper software shutdown and backup before removing power to prevent data loss. Avoid exposing the screen to strong ultraviolet light or flammable gases.
