Product Introduction:

  • The GE IS200DSPXH1DBC is a digital signal processor (DSP) control board designed for GE Mark VI and Mark VIe Speedtronic control systems. It performs complex control algorithms and real-time signal processing for turbine control and EX2100 exciter applications. It integrates a 60 MHz DSP, an ASIC, and memory to deliver high-speed processing with reliable performance
Request Quote
Category: SKU: GE IS200DSPXH1DBC

Description

GE IS200DSPXH1DBC

  • Technical Specifications:
    • Processor: 60 MHz digital signal processor
    • ASIC: Custom ASIC for specialized logic functions
    • Memory: Standard memory components; up to 248 kB SRAM and 512 kB Flash BIOS in related versions
    • Supply Voltage: 24 VDC
    • Power Consumption: Approximately 10 W
    • Operating Temperature Range: -40 °C to +85 °C
    • Relative Humidity: 5% to 95%, non-condensing
    • Dimensions: Approximately 13.39 inches × 8.5 inches × 2.17 inches
    • Weight: Approximately 2.2 pounds (about 1 kg)
    • Connectors: Backplane connector P1, vertical pin connector P7, engineering monitor port P6, DSP emulator port P5
  • Functional Characteristics:
    • Executes complex control algorithms, including speed control, excitation control, and protection functions
    • Provides high-speed data acquisition and processing capability
    • Supports integration with EX2100 exciter systems and Mark VI turbine control
    • Includes LED status indicators (red/green) for board fault and operational status
    • Supports engineering monitoring and DSP emulation via dedicated ports
  • Application Scenarios:
    • Gas and steam turbine control systems requiring high-speed processing
    • Excitation systems for generators in power plants
    • Compressor and pump control systems in the oil and gas industry
    • Industrial automation applications demanding real-time digital signal processing
  • Performance Parameters:
    • Fast processing speed enables deterministic control loop execution
    • Robust design supports continuous operation in demanding environments
    • Low-latency data paths ensure timely response to system events
  • Material and Structural Characteristics:
    • High-quality printed circuit board with conformal coating options
    • Aluminum front panel with mounting provisions
    • Connectors designed for secure and reliable interfacing
    • Components selected for reliability in high-temperature and high-vibration environments
  • Working Principle:
    • Runs control algorithms on the DSP, using the ASIC for specialized logic and interfacing
    • Interfaces with the system backplane for data exchange with other control modules
    • Processes sensor inputs and generates control commands for actuators
    • Provides diagnostic information via status LEDs and external ports
  • Installation Requirements:
    • Install into compatible Mark VI or Mark VIe racks ensuring proper alignment
    • Secure all connectors and verify engagement with backplane and external ports
    • Follow ESD handling procedures to avoid damaging sensitive components
    • Provide adequate cooling and ventilation within the cabinet
  • Usage Notes:
    • Ensure firmware compatibility with the rest of the control system
    • Use engineering ports only with approved equipment and under safe conditions
    • Monitor status LEDs regularly for early fault detection
    • Keep the board and surrounding area clean to prevent overheating and contamination
