GE IS200EPSMG2A
GE IS200EPSMG2A - Image 2

GE IS200EPSMG2A

Product Introduction:

  • The GE IS200EPSMG2A is a power supply module in the GE EX2100 excitation control system. It pairs with an EPDM module that supplies 125 VDC, providing converted power outputs such as 24 VDC to EDCF, EDEX, and EGDM modules. It also delivers isolated 70 VDC for contact wetting and includes three independent power supplies for the C, M1, and M2 controllers. This version (Group 2A) is not backward compatible with earlier revisions.
Request Quote
Category: SKU: GE IS200EPSMG2A

Description

GE IS200EPSMG2A

  • Technical Specifications:
    • Input Voltage: Paired with EPDM module providing 125 VDC
    • Outputs: 24 VDC to EDCF, EDEX, EGDM modules; isolated 70 VDC for contact wetting
    • Output Current: Up to 10 A (per typical EX2100 EPSM specifications)
    • Operating Temperature Range: -40 °C to +70 °C
    • Humidity: 5% to 95%, non-condensing
    • Weight: Less than 2 pounds
    • Protection: Overvoltage, overcurrent, short circuit, thermal protection
  • Functional Characteristics:
    • Converts input power from the EPDM module to required voltages for system components
    • Provides isolated 70 VDC contact wetting supply to improve reliability of digital inputs
    • Supplies three independent power rails for redundant controller configurations
    • Includes status indicators and protective features for reliable operation
    • Designed specifically for EX2100 exciter systems with tight integration
  • Application Scenarios:
    • Generator excitation systems in power plants
    • Industrial automation requiring robust and stable power supplies
    • Control systems where multiple voltage levels are required from a single source
    • Applications demanding high reliability and redundancy in power distribution
  • Performance Parameters:
    • Efficient power conversion with low heat generation
    • Maintains stable output voltages under varying load conditions
    • Supports redundant controller configurations with independent power supplies
  • Material and Structural Characteristics:
    • Compact printed circuit board assembly with heatsinks for thermal management
    • Industrial-grade components for long life and high reliability
    • Connector interfaces designed for secure and reliable connections
    • Constructed to meet stringent electrical and environmental standards
  • Working Principle:
    • Receives 125 VDC input from the EPDM module
    • Converts and regulates the input to multiple output voltages as required
    • Distributes power to designated modules via dedicated outputs
    • Monitors output conditions and activates protective functions when necessary
  • Installation Requirements:
    • Install in the EX2100 control cabinet as specified in system documentation
    • Ensure proper mounting and cooling to avoid overheating
    • Connect input and output wiring according to schematic diagrams
    • Verify compatibility with EPDM and other system modules before installation
  • Usage Notes:
    • Confirm input voltage and polarity before energizing
    • Regularly inspect connections and indicators for signs of wear or faults
    • Use only with compatible EPDM modules and system configurations
    • Follow manufacturer guidelines for testing and maintenance procedures
