GE IS200TBAIH1CCC

GE IS200TBAIH1CCC

Product Introduction: The IS200TBAIH1CCC is a high-performance analog I/O terminal board used in industrial control systems, particularly within the GE Speedtronic Mark VI turbine control system. It serves as a critical interface for acquiring and outputting analog signals.

Request Quote
Category:

Description

GE IS200TBAIH1CCC

Technical Specifications:

  • Brand: GE Fanuc / GE Digital
  • Model: IS200TBAIH1CCC
  • Product Type: Analog I/O Terminal Board
  • Series: RST Series
  • Channels: 8 channels (configurable as input or output)
  • Input Signal: 4-20 mA or 0-10 V
  • Output Signal: 4-20 mA or 0-10 V
  • Input Accuracy: ±0.1% FS (Full Scale)
  • Output Accuracy: ±0.2% FS
  • Response Time: Input ≤1 ms, Output ≤10 ms
  • Operating Temperature: -40°C to +85°C
  • Protection Rating: IP20
  • Dimensions: 120 mm × 80 mm

Functional Features:

  • High-precision analog signal acquisition and output
  • Optical isolation to suppress common-mode interference
  • Modular design supporting Plug-and-Play installation
  • Hot-swappable capability for easy maintenance
  • Supports temperature, pressure, and flow monitoring

Application Scenarios:

  • Smart grid monitoring (transformer oil temperature, gas pressure)
  • Chemical process control (reactor temperature regulation)
  • Manufacturing automation (robot arm positioning)
  • Gas turbine and steam turbine control systems

Performance Parameters:

  • Channel Count: 8
  • Accuracy: ±0.1% (Input), ±0.2% (Output)
  • Isolation: Photocoupler isolation

Material Composition:

  • High-quality printed circuit board (PCB)
  • Precision electronic components
  • Robust terminal blocks (TB1, TB2)

Structural Features: The board features two long black terminal blocks (TB1 and TB2) for field wiring and three long socket connector ports for data transmission and connection to other boards.

Working Principle: The board receives analog signals from field sensors, converts them to digital data for the controller (input), or receives digital commands to generate analog signals for actuators (output). It uses optical isolation to protect the control system from field noise.

Installation Requirements:

  • Mount on the designated backplane or rack.
  • Connect field wiring to the terminal blocks.
  • Ensure proper grounding to minimize noise.

Usage Notes:

  • Verify the signal type (current vs. voltage) matches the configuration.
  • Do not exceed the maximum input voltage.
  • In high-temperature environments, consider additional cooling or heat sinks.
