GE IS200TBQGH2A
Technical Specifications:
- Brand: General Electric (GE)
- Model: IS200TBQGH2A
- Product Type: I/O Terminal Board
- System Compatibility: Mark VI Speedtronic
Functional Features:
- Field Wiring Interface: Provides secure, organized termination points for field cables.
- Signal Routing: Routes analog, discrete, and thermocouple signals to the corresponding I/O boards via ribbon cables.
- Grounding & Shielding: Offers dedicated grounding points for cable shields to prevent noise interference.
Application Scenarios:
Deployed in every Mark VI I/O cabinet to safely transition field wiring to internal control electronics.
Performance Parameters:
- Signal Integrity: Optimized trace routing and shielding to maintain high-fidelity signals in noisy power plants.
- Reliability: High-current terminal blocks capable of withstanding continuous vibration.
Material Composition:
Industrial-grade screw terminals, copper busbars, and flame-retardant plastic housing.
Structural Characteristics:
Rugged DIN-rail mountable board with clearly labeled terminal blocks, cable strain reliefs, and plug-in ribbon connectors.
Working Principle:
Acts as a passive routing hub. Field wires are terminated on the board and internally connected via ribbon cables to active I/O boards for processing.
Installation Requirements:
Torque all terminal screws to the manufacturer’s specification to prevent arcing. Ensure ribbon cables are seated evenly and locked.
Usage Precautions:
Always verify field voltage before connecting wires. Use proper wire ferrules to prevent frayed strands from causing short circuits.
