Description
GE K116LSIGZ2PMR
Technical Specifications
- Part Number: K116LSIGZ2PMR
- Product Type: Industrial Control Relay / Contactor
- Manufacturer: General Electric
Functional Features
- Load Switching: Provides reliable make-and-break contacts for industrial loads.
- Circuit Isolation: Electrically isolates low-voltage control signals from high-power circuits.
- Status Indication: Provides visual feedback of contact position.
Application Scenarios
Motor control circuits, auxiliary equipment switching, and industrial control panels.
Performance Parameters
- Contact Rating: Rated for continuous industrial load currents.
- Mechanical Life: High-cycle endurance for frequent switching.
Material Composition
Heavy-duty electromagnetic coil, silver-alloy contacts, and robust insulating housing.
Structural Characteristics
Compact relay/contactor form factor with screw terminals and mounting brackets.
Working Principle
When control voltage is applied to the coil, the electromagnetic field pulls the armature, closing the main contacts to energize the load. When voltage is removed, a spring returns the contacts to the open position.
Installation Requirements
- Mount securely in an upright position.
- Torque terminal connections to specification.
- Verify coil voltage matches control circuit.
Usage Precautions
- Never exceed contact voltage or current ratings.
- Provide flyback diodes or snubbers for inductive loads.
- De-energize before servicing.
