Description
GE PNL21816G01
Technical Specifications:
- Brand: General Electric (GE)
- Model: PNL21816G01
- Product Type: Control Panel / Enclosure
- Application: Industrial Control Housing
Functional Features:
- Component Protection: Provides a secure, environmentally sealed enclosure for sensitive control electronics.
- Organized Wiring: Features pre-wired terminal blocks, DIN rails, and cable management for neat installation.
- Thermal Management: Designed with ventilation or cooling provisions to maintain optimal operating temperatures.
Application Scenarios:
Used to house Mark VI turbine control boards, PLCs, and power supplies in power plants and heavy manufacturing facilities.
Performance Parameters:
- Environmental Rating: IP-rated enclosure to protect against dust, moisture, and corrosive gases.
- Structural Integrity: Rigid construction to withstand industrial vibration and mechanical shock.
Material Composition:
Heavy-gauge steel or aluminum enclosure, powder-coated for corrosion resistance, with flame-retardant internal components.
Structural Characteristics:
Standard rack or panel dimensions with hinged doors, locking mechanisms, and precision-cut cutouts for connectors and displays.
Working Principle:
Acts as a passive protective housing. It routes incoming field power and signals to the internal control boards and provides a safe interface for operators.
Installation Requirements:
Mount securely to a flat, stable surface. Ensure adequate clearance around the enclosure for ventilation and door swing.
Usage Precautions:
Always close and lock the door after servicing to maintain the environmental seal. Do not drill or modify the enclosure without consulting the manufacturer.
