Description
GE SGLB36CB0400
Technical Specifications:
- Brand: General Electric (GE)
- Model: SGLB36CB0400
- Product Type: Molded Case Circuit Breaker
- Frame Size: SGL Frame
- Current Rating: 400A
Functional Features:
- Circuit Protection: Protects against overload and short circuit conditions.
- Thermal-Magnetic Trip: Provides dual-element protection for varying fault types.
- Manual Disconnect: Serves as a visible means of isolation for maintenance safety.
Application Scenarios:
Industrial motor circuits, feeder protection, and commercial building power distribution.
Performance Parameters:
Accurate trip characteristics, high interrupting rating, and long mechanical life.
Material Composition:
Arc-resistant thermoset housing, silver contacts, and precision trip mechanism.
Structural Characteristics:
Molded case with toggle handle, trip indicator, and standard bus connections.
Working Principle:
Continuously monitors circuit current and trips the mechanism when preset thresholds are exceeded.
Installation Requirements:
Install per NEC and local codes. Torque connections to manufacturer specifications.
Usage Precautions:
Test trip function annually. Replace if damaged or improperly tripped.
