Description
GE T60H00HCHF8HH6PM8HP6PUXXWXX
Technical Specifications:
- Brand: General Electric (GE) Multilin
- Model: T60H00HCHF8HH6PM8HP6PUXXWXX
- Product Type: Transformer Protection Relay
- System Compatibility: GE Multilin T60 Series
Functional Features:
- Comprehensive Protection: Provides primary and backup protection, including differential, overcurrent, and thermal protection.
- Advanced Monitoring: Features built-in oscilloscope, waveform capture, and actual value metering.
- Data Recording: Continuous data logging with trend analysis and export capabilities.
Application Scenarios:
Widely deployed in utility substations, industrial power distribution networks, and renewable energy integration points.
Performance Parameters:
- Communication Protocols: Supports Modbus RTU, Modbus TCP/IP, and DNP 3.0 over RS232, RS485, and Ethernet interfaces.
- Processing Speed: Fast fault detection and relay tripping times to minimize equipment damage.
Material Composition:
Housed in a rugged, flame-retardant industrial enclosure with high-quality copper busbars and gold-plated relay contacts.
Structural Characteristics:
Standard rack-mountable form factor featuring an enhanced LCD display, status LEDs, and intuitive navigation buttons.
Working Principle:
Continuously samples voltage and current waveforms via internal ADCs. The microprocessor runs real-time algorithms to detect fault conditions and executes predefined logic to trip circuit breakers.
Installation Requirements:
Must be securely mounted in a standard 19-inch panel. CT and VT secondary wiring must be correctly polarized and properly grounded.
Usage Precautions:
Always use the dedicated software for configuration changes. Ensure CT secondary circuits are never left open while the relay is energized.
