Description
ICS Triplex T8201
Technical Specifications:
- Module Capacity: Room for 6 power supply modules
- Power Input: Dual 24 VDC nominal supply
- Minimum Power per Supply: 250 watts
Functional Features:
- Six-module capacity for flexible power configurations
- Dual 24 VDC input for redundancy
- Compatible with T8220 15VDC power supply modules
- Robust chassis construction for industrial environments
- Support for redundant power architectures
Application Scenarios:
- Regent system power supply replacement
- Systems requiring multiple 15 VDC power supplies
- Applications with redundant power requirements
- Industrial control system power infrastructure
Performance Parameters:
- Reliable power distribution to all mounted modules
- Compatible with Trusted and Regent system architectures
- High availability through dual input design
Material Composition:
- Industrial-grade metal chassis
- High-current electrical connectors
- Durable mounting and retention hardware
Structural Characteristics:
- Standard industrial form factor
- Front-accessible module installation
- Integrated dual input power connections
- Proper ventilation for thermal dissipation
Working Principle: The chassis accepts dual 24 VDC inputs and distributes power to up to six mounted power supply modules. Each T8220 module converts the 24 VDC input to 15 VDC output for system use. The dual input design allows continuous operation even if one input source fails.
Installation Requirements:
- Dual 24 VDC power sources required
- Proper grounding connections mandatory
- Adequate ventilation must be provided
- Secure mounting in appropriate enclosure
Usage Precautions:
- Ensure both power inputs are properly connected
- Do not exceed maximum module capacity
- Verify proper module seating and retention
- Monitor power output indicators regularly
