Description
Kollmorgen 6SM37VL-6000
Technical Specifications
- Series: 6SM Synchronous Servo Motors
- Frame Size: 6SM37
- Rated Power: 1.19 kW
- Rated Speed: 6000 RPM
- Rated Torque: 3.0 Newton-meters
- Rated Voltage: 220/240 VAC
- Motor Type: Brushless synchronous servo motor
- Feedback: Resolver or encoder configuration
- Protection Rating: IP54 or higher depending on configuration
- Mounting: IEC standard flange
Functional Features
- High-speed capability up to 6000 RPM for rapid cycle applications
- Brushless design for maintenance-free operation
- Synchronous motor characteristics providing stable speed regulation
- Compatible with Kollmorgen Seidel 60WKS and 64WKS analog servo amplifiers
- Compact construction for space-constrained installations
Application Scenarios
- High-speed spindle drives
- Precision positioning systems
- Packaging machinery
- Printing equipment
- Automated assembly lines
- Industrial robotics
Performance Parameters
- 1.19 kilowatt power output at rated speed
- 3.0 Newton-meters torque at 6000 RPM
- High dynamic response for rapid acceleration and deceleration
- Smooth operation across the entire speed range
Material Composition and Structure
- Aluminum alloy housing with protective finish
- Neodymium or ferrite permanent magnets
- Class F or H insulation system
- Sealed bearings for extended service life
- Precision-balanced rotor for high-speed operation
Working Principle The motor operates as a brushless synchronous machine. Three-phase current from a servo amplifier energizes the stator windings, creating a rotating magnetic field that interacts with rotor permanent magnets to produce continuous torque. A resolver or encoder provides position feedback for electronic commutation and closed-loop speed control, enabling precise motion profiles at speeds up to 6000 RPM.
Installation Requirements
- Mount using IEC standard flange with proper alignment
- Use flexible coupling accommodating minor misalignment
- Connect to compatible Kollmorgen servo amplifier with appropriate cables
- Ensure adequate ventilation for high-speed thermal management
Operating Precautions
- Verify amplifier compatibility with motor winding parameters
- Do not exceed 6000 RPM maximum rated speed
- Monitor motor temperature during sustained high-speed operation
- Use shielded motor cables to prevent interference
- Ensure proper grounding of motor chassis
