Description
Kollmorgen CE06560
Technical Specifications
- Product Family: Kollmorgen Servo Drive Series
- Device Designation: CE06560
- Working Voltage: 230V
- Output Frequency: 60 Hz
- Protection Class: IP20 (standard), IP65 coating optional
- Quality Certification: CCC
- Housing Color: Blue
Functional Features
- High-Precision Vector Control: Advanced vector control technology for precise motor control
- Sensorless Vector Mode: Delivers 150% rated torque output at 3 Hz without encoder feedback, suitable for applications like printing machinery requiring high torque at low speeds
- Full Closed-Loop Control: Supports Resolver, Hiperface DSL, and other feedback devices with position control accuracy up to ±1 arc second
- Fast Dynamic Response: Current loop bandwidth ≥2 kHz, speed loop response time ≤1 ms, with overshoot of 0.5%
- Energy Regeneration: Built-in IGBT regeneration unit with braking energy recovery efficiency ≥95%
- Three-Level NPC Inverter: Output voltage harmonic THD ≤3% at 50 Hz, reducing motor temperature rise by 15K
Application Scenarios
- CNC Machine Tools: Feed axis and spindle drive for machining centers with nanometer-level positioning accuracy (positioning error ≤±0.001 mm)
- Industrial Robots: Six-axis robot joint drive with path repeatability ≤±0.02 mm
- Semiconductor Manufacturing: Wafer lithography and inspection equipment requiring sub-micron positioning
- Printing Machinery: High-speed registration control for precise paper tension and print speed synchronization
- Medical Equipment: CT scanners, MRI devices, and surgical robots requiring high-precision motion control
- Laboratory Automation: Sample processing and analytical instrument precision motion control
Performance Parameters
- Control Technology: High-precision vector control
- Position Control Accuracy: ±1 arc second
- Current Loop Bandwidth: ≥2 kHz
- Speed Loop Response Time: ≤1 ms
- Overshoot: 0.5%
- Braking Energy Recovery Efficiency: ≥95%
- Output Voltage THD: ≤3% at 50 Hz
Material Composition
- Metal housing with PCB boards featuring 3-layer protection (conformal coating + nano waterproof membrane)
- IGBT intelligent power modules
- Integrated control circuitry and heat dissipation components
Structural Features
- Form Factor: Compact servo drive module
- Mounting: Panel mounting inside control cabinets
- Connectors: Power input/output terminals, motor connection terminals, feedback connectors, and communication interfaces
- Status Indication: LED indicators for power, status, and fault conditions
- Enhanced Protection: PCB conformal coating with nano waterproof membrane for humidity resistance up to 95% (non-condensing)
