Description
Kollmorgen S443-M
- Technical Specifications:
- Series: ServoStar 400 (S400)
- Type: Servo drive module
- Power Rating: Approximately 1 kW (varies by specific suffix)
- Rated Voltage: 200V class (some variants support other voltage levels)
- Feedback Resolution: 24-bit high-resolution feedback
- Current Loop Bandwidth: 3–5 kHz
- Functional Features:
- Supports torque control, velocity control, and electronic gear modes
- Equipped with standard Molex interface and RJ45 interface (for SynqNet network communication)
- Comprehensive protection: overcurrent, overvoltage, undervoltage, and overtemperature protection
- High speed response frequency for rapid command tracking
- Application Scenarios:
- Industrial automation and robotics
- Aerospace and medical device manufacturing
- Packaging machinery
- Precision assembly systems
- Performance Parameters:
- High speed response frequency ensuring smooth system operation
- 24-bit feedback resolution for precise motion control
- Current loop bandwidth of 3–5 kHz for fast current response
- Material Composition:
- Industrial-grade metal housing
- IGBT power switching modules
- CE-certified components
- Structural Features:
- Module-style construction for panel mounting
- IP20 protection rating (suitable for control cabinet installation)
- Compact and lightweight design
- Working Principle:
- The drive receives motion commands via fieldbus or analog/digital inputs, processes them through embedded digital control loops, and outputs precisely modulated PWM signals to the connected servo motor. Feedback from the motor encoder is continuously compared against the command to minimize positioning error.
- Installation Requirements:
- Control room or control cabinet mounting
- Ensure adequate ventilation around the module
- Use shielded cables for all signal and power connections
- Usage Notes:
- Verify exact suffix (e.g., -S, -SE) for specific configuration details
- Ensure compatibility with the connected motor and feedback device
- This is a legacy product; contact Kollmorgen for suitable replacement options
