Description
Motorola MVME162-323
Technical Specifications
- Processor: MC68040 or MC68LC040.
- Storage: 1MB Flash, 512KB SRAM (battery-backed).
- Expansion: Supports IndustryPack modules and optional SCSI/Ethernet.
Functional Features
- Non-Volatile Resources: Onboard NVRAM and RTC ensure system configuration and timestamps are retained after power loss.
- Multi-Tasking Support: Hardware-level interrupt controller supports concurrent multi-task processing.
- Long Lifecycle: As a mature product, it offers extensive spare parts availability and technical support.
Application Scenarios
Power monitoring systems, large machinery motion control, and medical equipment consoles.
Performance Parameters
- Operating Temperature: Commercial grade 0°C to 55°C.
- Data Transfer: Supports A24/A32 address space and D32/D64 data transfers.
Material Composition
Industrial-grade electronic components, strictly screened and burn-in tested.
Structural Characteristics
6U Eurocard format with clear silkscreen markings on the front panel.
Working Principle
Interacts with the system via the VME bus, utilizing the local bus for high-speed I/O operations to reduce VME bus load.
Installation Requirements
- Inspect VME slot guides for debris before installation.
- Ensure cooling fans are operating normally.
Usage Precautions
- Avoid frequent power cycling to extend the life of the onboard backup battery.
- Disconnect all external connections before making hardware modifications.
