Description
OMRON C200HW-PA204S
Technical Specifications:
- Brand: OMRON
- Model: C200HW-PA204S
- Product Type: AC Power Supply Unit
- Compatible System: C200HW Series PLC
- Input Voltage: 100V to 240V AC
- Input Frequency: 50/60 Hz
- Output Voltage: 5V DC
- Output Current: 4.6A
- Output Power: 30W
- Certifications: CE, CSA, Lloyd, NK, UL
- Protection Rating: IP30
- Operating Temperature: 0°C to 55°C
- Mounting: Backplane mount
- Termination Type: Screw terminals
Functional Features:
- Wide input voltage range (100V to 240V AC)
- 5V DC output at 4.6A (30W) for backplane power
- Built-in protection against overcurrent and overvoltage
- Screw terminal connections for reliable wiring
- Complies with multiple international safety standards
- Designed for industrial environment durability
Application Scenarios:
- C200HW series PLC power supply
- Industrial automation control panels
- Manufacturing process control systems
- Machine control applications
- Any application requiring reliable PLC power
Performance Parameters:
- Input Voltage: 100V to 240V AC
- Output Voltage: 5V DC
- Output Current: 4.6A
- Output Power: 30W
- Efficiency: High-efficiency switching regulation
Material Composition:
- Industrial-grade electronic components
- Switching power supply circuitry
- Metal chassis with plastic housing
- Screw terminal blocks
Structural Features: The C200HW-PA204S is a modular power supply unit that mounts directly onto the C200HW series backplane. The front panel features screw terminals for AC power input and status LED indicators showing power-on and fault conditions.
Working Principle: The -PA204S uses a switching power supply circuit to convert the incoming AC voltage (100V to 240V AC) into a stable, regulated 5V DC output. This DC power is supplied to the PLC backplane, which distributes it to the CPU unit and all installed I/O and special function modules.
Installation Requirements:
- Mount on series backplane
- Connect AC power using screw terminals
- Ensure proper grounding of the power supply
- Provide adequate ventilation for heat dissipation
- Verify input voltage matches the rated range before powering on
Usage Notes:
- Do not exceed the 30W output capacity
- Ensure all module current requirements are within the power supply capacity
- Check screw terminal tightness periodically
- Do not perform insulation resistance tests on the unit
- Store in dry, anti-static conditions
