OMRON CS1W-PTS52
Technical Specifications:
- Brand: OMRON
- Model: CS1W-PTS52
- Product Type: Resistance Thermometer Input Unit
- Compatible System: CS1 Series PLC
- Number of Inputs: 4 channels
- Input Type: Pt100 (JIS/IEC), JPt100
- Conversion Speed: 250 ms / 4 inputs
- Accuracy: ±0.3% of PV or ±0.8°C (whichever is greater)
- Isolation: Channel-to-channel and PLC isolation
- Power Consumption: 0.25 A at 5 VDC
- Dimensions: 35 mm (W) × 130 mm (H) × 100 mm (D)
Functional Features:
- 4-channel isolated input for resistance thermometers
- Supports Pt100 and JPt100 sensors
- High accuracy and stability
- Burnout detection (upper/lower limit)
- Removable terminal block
Application Scenarios:
- Temperature monitoring and control
- Process industries (chemical, food, pharmaceutical)
- HVAC systems
- Industrial ovens and furnaces
Performance Parameters:
- Input Channels: 4
- Sensor Type: Pt100, JPt100
- Conversion Speed: 250 ms (all 4 channels)
- Accuracy: ±0.3%
Material Composition:
- Precision measurement circuitry
- Multi-layer printed circuit board
- Plastic housing
- Removable terminal block
Structural Features: The unit features a compact 35mm width. The front panel includes a removable terminal block for sensor wiring.
Working Principle: The unit excites the resistance thermometer with a constant current, measures the voltage drop, and calculates the temperature based on the resistance-temperature characteristic. The signal is isolated and converted to digital data for the CPU.
Installation Requirements:
- Mount on CS1 series CPU rack or expansion rack.
- Use 3-wire or 4-wire connection for Pt100 sensors to minimize lead resistance errors.
- Ensure proper grounding.
Usage Notes:
- Verify the sensor type (Pt100 vs JPt100) matches the configuration.
- Do not apply voltage to the input terminals.
- Ensure the wiring is secure to prevent measurement errors.
